Castleberry gyros repair & overhaul
Castleberry attitude indicators, flight director gyros and directional gyros are no longer in production. We repair and overhaul the ones still flying, at our shop in Show Low, Arizona.
The Castleberry line
Castleberry models we support
Castleberry gyros grew out of the AIM gyro line. In Austin, Castleberry developed its 900 series electric gyros to replace most of the discontinued AIM 510 series, then added models ruggedized for helicopters and lighting for night vision goggles. In 2005, Sporty's Pilot Shop offered an electric backup attitude indicator made by Castleberry.
The line is no longer in production. The models below are the ones in the most recent Castleberry product brochure, with the features it lists for each.
Configurations varied by part number. Check the data plate on your instrument, or send us the part number and we'll confirm what it is.
Attitude indicators
Castleberry attitude indicators
Gyro horizons in 3-inch cases, for vacuum, DC or 115-volt power, in fixed-wing and helicopter panels.
-
Attitude indicator
300-14 series
A 3-inch attitude indicator for vacuum or DC power, front or rear mount.
- 3-inch case, front or rear mount
- Various panel tilts
- Power: vacuum, 14 or 28 VDC, or 10–32 VDC
- Failure warning flag and rotating dial
- Optional autopilot outputs
- Lighting: BW, W or NVIS
- FAA TSO-C4c
-
Electric attitude indicator
900-23EH series
Ruggedized for helicopter vibration, for fixed-wing or helicopter panels.
- 3-inch case, front or rear mount
- Various panel tilts
- Power: 14 or 28 VDC
- Failure warning flag and rotating dial
- Optional radar stabilization
- DO-160 vibration curve
- Lighting: BW, W or NVIS
- FAA TSO-C4c
-
Electric attitude indicator
900-23EPHD
An electric attitude indicator with an autopilot output and an optional ARINC 429 output.
- 3-inch case, rear mount
- Various panel tilts
- Autopilot output; optional ARINC 429 output
- Power: 10–32 VDC
- Failure warning flag and rotating dial
- DO-160 vibration curve
- Lighting: BW, W or NVIS
- Fixed-wing or helicopter
- FAA TSO-C4c
-
115-volt attitude indicator
900-23EPAR
An electric attitude indicator for 115-volt power, with manual caging for a quick erect.
- 3-inch case, rear mount
- Various panel tilts
- Power: 115 V
- Optional autopilot output and radar stabilization
- Failure warning flag and rotating dial
- Manual caging for quick erect
- Lighting: BW, W or NVG
- FAA TSO-C4c
Flight director gyros
Castleberry flight director gyros
Attitude indicators with command bars, for S-Tec, Century Flight Systems and Bendix/King autopilots.
-
Vacuum flight director gyro
900-23V series
A vacuum-driven flight director gyro for S-Tec autopilots.
- Rear mount in shock-mounted panels
- 0° or 8° panel tilt
- Vacuum driven
- Optional radar stabilization
- Lighting power: 14, 28 or 5 VDC
- Lighting: BW, W or NVIS
-
Electric flight director gyro
900-23EVPC
An electric flight director gyro for Century Flight Systems autopilots.
- Rear mount in shock-mounted panels
- Various panel tilts
- Power: 14 or 28 VDC
- Lighting power: 14, 28 or 5 VDC
- Lighting: BW, W or NVG
-
Electric flight director gyro
900-23EVPS
An electric flight director gyro for S-Tec autopilots, with radar stabilization.
- Rear mount in shock-mounted panels
- Various panel tilts
- Radar stabilization
- Power: 14 or 28 VDC
- Lighting power: 14, 28 or 5 VDC
- Lighting: BW, W or NVIS
-
Bendix/King version
KI-254 replacement
The Castleberry brochure also lists a front-mount 900-23EVPC flight director gyro that replaces the KI-254, for Bendix/King autopilots.
- Front mount
- Various panel tilts
- Power: 10–30 VDC
- Lighting: BW, W or NVIS
Directional gyro and accessories
Directional gyro, emergency power and inverter
The 200 series directional gyro, with the emergency power unit and the inverter that complete the Castleberry line.
-
Directional gyro
200 series
A directional gyro with a fixed-wing or helicopter display, and an optional heading bug and autopilot outputs.
- 3-inch case, rear mount in shock-mounted panels
- Fixed-wing or helicopter display
- Optional heading bug and autopilot outputs
- Power: vacuum, 14 or 28 VDC, or 10–32 VDC
- Failure warning flag
- Lighting: BW, W or NVIS
- FAA TSO-C5c
-
Emergency power unit
EPU28-24RM series
Powers up to two instruments if the aircraft's electrical system fails. A TSO'd replacement for older Terra and AIM units, which were not TSO'd.
- Compact and lightweight
- Input: 14 or 28 VDC
- Output: 14, 24 or 28 VDC
- Capacity: 2.5 Ah at 24 and 28 VDC, 5.0 Ah at 14 VDC
- Remote self-test
- DO-160D
-
Inverter
PAC-75
Converts 28 VDC to 115 and 26 VAC at 400 Hz. A TSO'd replacement for older AIM inverters, which were not TSO'd.
- Compact and lightweight
- Input: 28 VDC
- Output: 115 and 26 VAC, 400 Hz, 75 VA
- FAA TSO-C73
Part numbers
Check your Castleberry part number
Find the part number on your Castleberry instrument's data plate and send it to us. We'll confirm the model and recommend repair or overhaul.
Have this ready
- Part number from the data plate
- What the instrument is doing, or not doing
- The autopilot, for a flight director gyro
- Your company, name, phone and email
A gyro is fragile in transit, so pack it with care. How to pack and ship it
